Configure your order
1Select variant
2Select output power
3Your configuration
Part NumberSLCE-561
Beam ModeTEM₀₀
PerformanceStandard
Power Stability< 1% RMS
Beam QualityM² < 1.5
Beam Diameter< 2 mm at aperture (1/e²)
Dimensions (mm)197 × 70 × 50 mm
Selected Power50 mW
Typical Applications
Laser Medical TreatmentScientific ExperimentsOptical InstrumentsFluorescence Microscopy
Common Specifications
| Laser Type: | DPSS Laser | Modulation: | DC – 30 kHz, TTL/Analog | |
| Polarisation: | > 100:1 | Interface: | RS-232 | |
| Beam Diameter: | < 2 mm at aperture (1/e²) | Dimensions (mm): | 197 × 70 × 50 mm | |
| Start-Up Time: | < 5 min | Power Supply: | 100–240 VAC, 50/60 Hz | |
| Operating Temp.: | 10 – 35 °C |
Key Features
- All-solid-state DPSS design — no alignment required
- TEM₀₀ output with M² < 1.5 (standard/LN) and M² < 1.2 (Pro) across all variants
- Three performance tiers from high-power standard through precision Pro
Need a custom configuration?
OEM integration, custom power levels, and fibre-coupled variants available on request.
