Part NumberDLCE-1030
Beam ModeTEM₀₀
PerformanceStandard
Power Stability< 1% RMS
Beam QualityM² < 1.1
Beam Diameter~ 1.0 mm at aperture (1/e²)
Dimensions (mm)146 × 58 × 45 mm
Selected Power100 mW
Typical Applications
SpectroscopyTelecommunicationAdvanced Research
Common Specifications
| Laser Type: | Diode Laser | Modulation: | DC – 30 kHz, TTL/Analog | |
| Beam Diameter: | ~ 1.0 mm at aperture (1/e²) | Interface: | RS-232 | |
| Start-Up Time: | < 5 min | Dimensions (mm): | 146 × 58 × 45 mm | |
| Operating Temp.: | 10 – 35 °C | Power Supply: | 100–240 VAC, 50/60 Hz |
Key Features
- Single-mode IR diode laser at 1030 nm with TEM₀₀ beam and M² < 1.1
- Standard and low-noise variants deliver up to 500 mW with diffraction-limited beam quality
- Compact form factor with fibre-compatible output for spectroscopy and telecom integration
- Active power stabilisation for consistent long-term output
Need a custom configuration?
OEM integration, custom power levels, and fibre-coupled variants available on request.
